CONVEX® Rotisseries
Home » Foodservice Equipment » Rotisseries » CONVEX®-Rotisserie
CONVEX® Rotisserie CC – Rotisserie with automatic self-cleaning system
The globally used CONVEX® rotisserie with automatic control and brand new computer control provides the future of grilling.
The new, intelligent computer control with capacitive 7.2″ glass display, touch sensor technology and multilingual plain text user guidance.
The rotisserie is uniquely equipped with Wireless Radio Technology (WRT), i.e. with permanent core temperature measurement including real cooking time adjustment via wireless core temperature sensors (optional). For ideal cooking times and perfect grilling results!
3 heating systems – infrared, convection and steam injection – in one unit. Pass-through design for professional work according to HACCP Efficient and closed 4-jet convection system. Convex, frameless panoramic double glazing for perfect insulation and safety.
200 subdivisible programmes. Boost function and monitoring of the heating elements. USB interface for backup and restor of all programmes and customer settings. Planned LAN connection for external creation/modification of cooking programmes. Operating hours counter and monitoring of the grease collector. Password-protected programming and parameterisation level. Any language can be installed. 8 spit or basket positions with a capacity of 40 to 48 chickens. With wired core temperature sensor as standard.
If desired, two units of the CONVEX Rotisserie RT608CC can be mounted on top of each other and connected to form a double-tier rotisserie. For ergonomic reasons, the controls of both units are placed in the upper unit. However, the units are operated independently of each other.
The result: with the RT616CC, the customer gets twice the grilling capacity but on the footprint of just one appliance!
All the features and functions of the units are retained: Whether pass-through design or self-cleaning, whether computer control or heating systems!
Model | Dimensions (WxDxH mm) | Connection Load | Downloads |
---|---|---|---|
RT606CC CONVEX® Rotisserie Capacity 6 Spits for 24 - 30 Chickens or 55kg var. grill food | 800 x 789 x 1065 | 7,5 kW, 400 V | Download
|
RT608CC CONVEX® Rotisserie Capacity 8 Spits for 40 - 48 Chickens or 85kg var. grill food | 1000 x 938 x 1210 | 12,3 kW, 400 V | Download
|
RT616CC CONVEX® Rotisserie Capacity 16 Spits for 80 - 96 Chickens or 170kg var. grill food | 1000 x 938 x 2225 | 24,6 kW, 400 V | Download
|
